Performance Grade (PG) bitumen is bitumen which is graded based on its performance at different temperatures. The Futrol has given a certain algorithm to calculate the temperature of the pavement based on the temperature of the air above. From this, the highest and the lowest temperatures of the pavement is calculated and the bitumen that performs well in that temperature range is selected.
This Bitumen is being used in Road, Airport constructions.
Royal Global Energy is the Top bitumen company Iran which is the answer of all modern and time-tested problems and need for highest quality of bitumen performance grade. The Bitumen performance grade that is most suitable binder for pavement performance in terms of grooving, cracking, and low temperature cracking by the bitumen company in Pakistan. Our bitumen performance grade is manufactured with the best variety of raw materials.
The Bitumen PG grades produce the best quality of bitumen performance grade in all over bitumen companies in Iran. The main reason of grading and selecting asphalt binder in Iran is to decide which type of binder is suitable for environmental conditions in the field. PG asphalt binders are chosen to meet expected weather conditions as well as traffic speed and volume. So, the performance grade is done to check the physical properties of the binder which can be directly related to the performance of the field pavement by the asphalt companies.
The bitumen grade 60 70 price in Iran also varies. You can order your product in a very economically and cheap price as compared to other asphalt companies in Iran. Bitumen performance grader is uses as:
- The construction of new paving and pavement rehabilitation.
- Sealing the edges of new and old paving.
- Also sealing the cracks.
- Spraying method for bridge deck and pavement protective membrane with fabrics.
- For the production of Hot Mix Asphalt (HMA) which is manufactured in the bitumen hot mix plant.
- We also use performance grade on the high elevation roadways and many more
The main grades for bitumen emulsions are classified as follows:
| Bitumen Performance Grade | Pg 46-34 | Pg 46-28 | Pg 52-28 | Pg 58-28 | Pg 58-22 | Pg 64-22 | AASHTO Method |
|---|---|---|---|---|---|---|---|
| Original Binder | |||||||
| Flash Point, COC,°C | 230 | T48 | |||||
| Flash Point, P-M, °C | NS | ≥ 204 | ASTM D93 | ||||
| Rotational Viscosity @ 135°C, Pa·s | 3.00 | T 316 | |||||
| Dynamic Shear @ Grade Temperature,°C | 46 | 46 | 52 | 58 | 58 | 64 | T 315 |
| G*/sin @ 10 rad/sec, kPa | ≥ 1.00 | ||||||
| RTFOT Residue | |||||||
| Mass Loss, % | ≤ 1.00 | T 240 | |||||
| Dynamic Shear @ Grade Temperature,°C | 46 | 46 | 52 | 58 | 58 | 64 | T 315 |
| G*/sin @ 10 rad/sec, kPa | 2.20 | T 315 | |||||
| PAV Residue (Aging Temperature, °C) | 90 | 100 | R 28 | ||||
| Dynamic Shear @ Grade Temperature,°C | 10 | 13 | 16 | 19 | 22 | 25 | T 315 |
| G*/sin @ 10 rad/sec, kPa | 5000 | T 315 | |||||
| Creep Stiffness | -24 | -18 | -18 | -18 | -12 | -12 | T 315 |
| S, Mpa | ≤ 300 | T 313 | |||||
The above table shows a complete illustration of Bitumen Performance Grade, Royal Global Energy has a full range of Bitumen Grade. Thus most used grade in bitumen performance grade.
SPECIFICATION FOR PERFORMANCE GRADE BITUMEN
| PROPERTY | GRADES | STANDARD | |||
| PG 76-10 | PG 82-10 | ||||
| Min | Max | Min | Max | ||
| Flash Point, COC, °C | 230 | – | 230 | – | T48 |
| Viscosity @ 135°C, Pa·s | 135°C | 3.0 | 135°C | – | ASTM D4402 |
| Dynamic Shear @ 70°C, G*/sin d, kPa | 1.00 | – | – | – | – |
| After RTFO | – | – | – | – | – |
| Dynamic Shear @ 70°C, G*/sin d, kPa | 2.20 | – | – | – | – |
| Mass Loss, % | – | 1% | – | 1% | – |
| After PAV @ 100°C | – | – | – | – | – |
| Dynamic Shear @ 28°C, G*·sin d, kPa | – | 5000 | – | – | – |
| Creep Stiffness @ -12°C, S, MPa | – | 300 | – | – | – |
| Creep Stiffness @ -12°C, M-value | 0.300 | – | – | – | – |
PG is the latest standard of the day. This relatively new method classified bitumen is based on varying temperatures. It is a fully scientific method studying the mechanical specifications of bitumen. In this method, a temperature range is defined for bitumen and the consumer can easily choose the desired product. Having installed SHRP systems, Royal Global Energy is capable of selling bitumen to its customers based on PG method. Today, a PG is defined for polymer modified bitumen and pure bitumen based on environmental conditions and temperature. A wider PG range means higher resistance and more favorable specifications. Royal Global Energy has the capacity to produce all these grades. This company first conducted climate zoning in Iran to specify the appropriate bitumen for different geographical zones.
PG Bitumen
| High Temperature Performance | Low Temperature Performance |
|---|---|
| PG 46 | -34, -40, -46 |
| PG 52 | -10, -16, 22-, -28, -34, -40, -46 |
| PG 58 | -10, -16, 22-, -28, -34, -40 |
| PG 64 | -10, -16, 22-, -28, -34, -40 |
| PG 70 | -10, -16, 22-, -28, -34, -40 |
| PG 76 | -10, -16, 22-, -28, -34 |
| PG 82 | -10, -16, 22-, -28, -34 |
Performance Grades Bitumen
- PG 52 – 10
- PG 52 – 16
- PG 52 – 22
- PG 58 – 10
- PG 58 – 16
- PG 58 – 22
- PG 64 – 10
- PG 64 – 16
- PG 64 – 22
- PG 70 – 10
- PG 70 – 16
- PG 76 – 10
